Engine Test Facilities Industries
Engine test benches are crucial instruments to perform tests on internal combustion engines. Possible purposes of these tests are to detect the engine performance, check the reliability of the components or make a proper calibration of engine control systems managing the actuations. Since many factors affect tests results in terms of performance, emissions and components durability, an engine test bench is equipped with several conditioning systems (oil, water and air temperature, air humidity, etc.)
One of the most important systems is the HVAC (Heating, Ventilating and Air Conditioning), that is essential to control the conditions of the intake air. Intake air temperature, pressure and humidity should be controllable test parameters, because they play a key role on the combustion development. In fact, they can heavily affect the performance detected, such as power and specific consumption, and, in some cases, they may promote knock occurrence.
This work presents an HVAC model-based control methodology, where each component of the air treatment system (humidifier, pre-heating and post-heating resistors, chiller and fan) is managed coupling open-loop and closed-loop controls. Each branch of the control model is composed of two parts, the first one to evaluate the target for the given HVAC component, based on the system physical model, the second one is a PID controller based on the difference between the set-point and the feedback values. The control methodology has been validated on an engine test bench where the automation system has been developed on an open software Real-Time compatible platform, allowing the integration of the HVAC control with all other functionalities concerning the test management. The paper shows the plant layout, details the control strategy and finally analyzes experimental results obtained on the test bench, highlighting the benefits of the proposed HVAC
Efficiency and Reliability
It is not all about temperature and humidity control, though. Efficiency and reliability also play an important role in the investment companies do choosing equipment for their HVAC system. Pharmaceutical companies, like any other company, need to make sure costs are contained. Since HVAC systems can have an important impact on energy expenditures, it is important to choose energy- efficient units.
We know value of customer time, value of product losses, breakdown time & system failure so we follow all the industrial standards and Guidelines as mentioned below :
- Sheet Metal & Air Conditioning contractors National Association (SMACNA)
- American Society of Heating, Refrigerating and Air Conditioning Engineers (ASHRAE)
- Indian Society of Heating, Refrigerating and Air Conditioning Engineers (ISHRAE)
- National Building code of India (NBC)
We offering different type of systems to fulfill and type of Cleanroom classification like Air cooled chiller plant & AHU; Water cooled Chiller plant with AHU & Direct expansion plant with AHU.
| *** 14644-1 | FEDERAL STANDARD 209E | |
|---|---|---|
| ISO Class | English | Metric |
| *** 1 | - | - |
| ISO 2 | - | - |
| ISO 3 | 1 | M1.5 |
| ISO 4 | 10 | M2.5 |
| *** 5 | 100 | M3.5 |
| ISO 6 | 1,000 | M4.5 |
| ISO 7 | 10,000 | M5.5 |
| *** 8 | 100,000 | M6.5 |
| ISO 9 | ||
